Foton BOX 4x4 Diesel Mini Truck Van New Automatic Transmission Rear FAST Gearbox Euro III 5-ton Fact
![[pics:title]](https://clwtrucksgroup.com/static/upload/other/20251114/1763118749726596.jpeg)
![[pics:title]](https://clwtrucksgroup.com/static/upload/other/20251114/1763118748637000.jpeg)
![[pics:title]](https://clwtrucksgroup.com/static/upload/other/20251114/1763118748342399.jpeg)
![[pics:title]](https://clwtrucksgroup.com/static/upload/other/20251114/1763118749637916.jpeg)
![[pics:title]](/static/upload/other/20251114/1763118749726596.jpeg)
![[pics:title]](/static/upload/other/20251114/1763118748637000.jpeg)
![[pics:title]](/static/upload/other/20251114/1763118748342399.jpeg)
![[pics:title]](/static/upload/other/20251114/1763118749637916.jpeg)
Parameter Category | Detailed Data |
Basic Vehicle Information | |
Announcement Model | BJ5048XXY8JEA-AB9 |
Vehicle Type | Box Van Truck |
Drive Configuration | 4×2 (2 front steering wheels + 2 rear driving wheels) |
Wheelbase | 3360 mm |
Cargo Box Length Class | 4.2 m |
Engine Model | Foton Cummins F2.5NS6B172 |
Transmission Model | Wanliyang WLY6GS40 |
Rear Axle Ratio | 4.875 |
Overall Vehicle Length | 5.995 m |
Overall Vehicle Width | 2.18 m |
Overall Vehicle Height | 3.44 m |
Front Track Width | 1730 mm |
Rear Track Width | 1615 mm |
Curb Weight | 2.805 tons (2805 kg) |
Rated Payload Capacity | 1.495 tons (1495 kg) |
Gross Vehicle Weight (GVW) | 4.495 tons (4495 kg) |
Maximum Speed | 110 km/h |
Place of Origin | Suizhou, Hubei (China) |
Tonnage Class | Light Truck |
Approach Angle | 20° |
Departure Angle | 16° |
Remarks | Optional: 3/8+6 leaf springs, 4.333 rear axle ratio |
Front Overhang/Rear Overhang | 1.11 m / 1.525 m |
License Plate Type | Blue License Plate (Compliant with China’s light-duty vehicle license standards) |
Energy Type | Diesel |
Engine Parameters | |
Engine Brand | Foton Cummins |
Engine Model | Foton Cummins F2.5NS6B172 |
Engine Series | Foton Cummins 2.5L |
Number of Cylinders | 4 Cylinders |
Fuel Type | Diesel |
Cylinder Arrangement | In-line |
Displacement | 2.498 L |
Emission Standard | Euro III |
Maximum Output Power | 120 kW |
Maximum Horsepower | 163 HP |
Maximum Torque | 460 N·m |
Maximum Torque Speed Range | 1500 - 1800 rpm |
Rated Engine Speed | 2900 rpm |
Transmission Parameters | |
Transmission Model | Wanliyang WLY6GS40 |
Transmission Brand | Wanliyang |
Shifting Mode | Manual |
Number of Forward Gears | 6 Gears |
Number of Reverse Gears | 1 Gear |
Cargo Box Parameters | |
Cargo Box Type | Box-type (Enclosed van structure for cargo protection) |
Cargo Box Length | 4.14 m |
Cargo Box Width | 2.1 m |
Cargo Box Height | 2.1 m |
Internal Cargo Box Width | 2.1 m |
Cab Parameters | |
Cab Type | Medium-sized Cab |
Cab Width | 1880 mm |
Approved Passenger Capacity | 3 Seats |
Seat Row Configuration | Single-Row |
Q1:Could your company manufacture products based on my requests?
A:Yes. With our R&D team, Chengli is specialized in engineering and making specialized vehicles. We can provide any products according to your demands, like the volume, painting, size, logo, the engine, and even the chassis.
Q2:What's your quality guanrantee?
A:We are a government-certified enterprise recognized by China's Ministry of Industry and Information Technology (MIIT), we have passed the ISO, CCC, SGS. We also hold export qualifications.
Q3. What are your main products?
A: Fire and emergency response vehicles, tanker trucks, refrigerated trucks, sanitation trucks, garbage truck, sprinkler truck, boom truck, wrecker trucks and so on. The annual production capacity is exceeding 8,000 units.
Q4. Are you a factory or trading company?
A: Chengli a the original factory, not a middleman or agent.
Q5. What are your terms of payment? What is your terms of delivery?
A: Generally speaking, 30% T/T deposit in advance. Terms are EXW, FOB, CFR, CIF.
Q6. How about your delivery time?
A: 10 to 25 days after receiving your advance payment. It also depends on the items and the quantity.
Q7. What is the price of your product?
A: We are the direct factory, so the price can be competitive. Visit our company and let us enjoy a tea to further talk about the price!
Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q9.What is the warranty period for your products?
A:The warranty period of export vehicles can be 12 months, based on the order.
Q10.Do your special vehicles comply with national/regional safety standards and emission regulations?
A:Yes.
Q11.What after-sales services do you provide?
A:We provide comprehensive after-sales services, including free parts, maintenance, repairs, technical support, and on-line tech support.
Q12:Can you make OEM or ODM?
A:Yes, we welcome the importer and wholesaler from worldwide for OEM and ODM business.
Q13:Where is your factory located? How can I visit there?
A:The address is at the intersection of Xingguang Road 1 and National Highway 316 in Zengdu Economic and Technological Development Zone, Suizhou City, Hubei Province, China. We will pick you up at Wuhan Airport.
